SDI Color PrecisionĪutomatically selects between SD-SDI, HD-SDI, 6G-SDI and DVB-ASI on each input so that each input can be running a different television standard. Television standard sample rate of 48kHz and 24 bit. SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M Level A and B, ITU-R BT.656 and ITU-R BT.601.
BLACKMAGIC SMART VIDEOHUB 12X12 MANUAL SOFTWARE
HD Video Standardsġ080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60ġ080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30ġ080i50, 1080i59.94, 1080i60 2K Video StandardsĢK DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF Ultra HD Video StandardsĢ160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30 4K Video StandardsĤK DCI 23.98p, 4K DCI 24p, 4K DCI 25p SDI Compliance 1 - to restore the telnet and Videohub Control and Setup Software operation, we had to run the setup after setting videohub to its original ip 192.168.10.150 2 - to solve the proxy problem, we have set up a static route in Windows We reported this troubleshooting to BM support so that they can analyse it and consider it in future software releases.
BLACKMAGIC SMART VIDEOHUB 12X12 MANUAL PATCH
The advantage of SDI embedded audio means that you can route or directly patch synchronized audio and video on a single cable!ĥ25i59.94 NTSC, 625i50 PAL. If you need to route audio to analog equipment, it can easily be de-embedded from the SDI signal using Mini Converters. That means you get up to 16 mono or 8 stereo channels perfectly synchronized with your video. The SDI standard includes 16 channels of embedded audio with your video signal. Broadcast designers, editors, and colorists using Mac or PC workstations can use the free Videohub Control Software to instantly switch and route the signals they need over ethernet! Routing changes can be made without a computer by pressing the numbered pushbuttons on the front control panel.
These models feature a built in control panel and LCD. All Videohub hardware control panels include industry standard Ethernet connections, making it easy to install them throughout your facility. Smart Videohub routers include Blackmagic Smart Videohub 12x12, 20x20 and 40x40, plus Smart Videohub CleanSwitch 12x12. The Smart Videohub can be controlled with remote hardware panels or via software over standard ethernet networks.
BLACKMAGIC SMART VIDEOHUB 12X12 MANUAL FOR MAC
Also includes Ethernet for remote control and a fully customizable software development kit for Mac and Windows.Įthernet is one of the most common computer networking standards and is used to provide connectivity in virtually every facility worldwide. You also get revolutionary new visual routing with the unique spin knob control, push button panel and the built in LCD screen. Description Compact 6G-SDI router with built in re-synchronizers on all inputs allows clean switching between all video sources of the same video standard.Display: Built in LCD for video and menu settin. Ideal for small workgroups and fly away kits, it includes advanced 6G-SDI connections so you can simultaneously connect and route any combination of SD, HD and Ultra HD video all on the same router at the same time. Smart Videohub 12×12 is the world’s most advanced Ultra HD mixed format router with built in control panel and monitoring.
